nRF24AP2-1Ch (NRND)

Overview

A highly integrated 1-channel ANT network processor from Nordic Semiconductor. Including the enhanced ANT core stack and offering sub-17mA peak currents, average currents as low as 11μA, and a 1.9 to 3.6V supply range, the nRF24AP2-1CH enables battery lifetimes of months to years from a single coin cell. The integrated 2.4GHz RF transceiver core is based on the nRF24L01+ and provides significant sensitivity and co-existence performance improvements. nRF24AP-1CH ideally suited for battery-operated sensors.

The nRF24AP2-1CH is available in QFN 5x5 package.

Manufacturer's Product Page

Advanced Features

  • High density node support – up to 300 nodes at 1 Hz Tx rate in same RF space
  • Frequency agility
  • Proximity search
  • Scanning mode – extremely low latency for asynchronous applications such as remote control
  • Low priority search – does not impact existing channels
  • Channel ID management – improves device pairing efficiency
  • Individual output power control per channel

Basic ANT Features

  • 78 selectable RF channels (2403 to 2480MHz)
  • Simple sync/async serial interface
  • On chip 32.768 kHz crystal oscillator
  • Broadcast, acknowledged, or burst data transmissions
  • Simple to complex network topologies: Peer-to-peer, star, tree and practical mesh
  • ANT channel combined message rate up to 190Hz (8 byte data payload)
  • Minimum message rate per ANT channel 0.5Hz
  • Burst transfer rates up to 20Kbps (true data throughput)
  • Up to 8 ANT channels
  • Up to 3 public, managed and/or private network keys
  • 2.0V to 3.6V supply voltage range
  • -40°C to +85°C operating temperature
  • RoHS compliant
